Paxton Net2 Access Control Binding

This binding provides integration with the Paxton Net2 Access Control system via its REST API, enabling door control, real-time status monitoring, access logging, user management, and building lockdown – all from openHAB.

Features

  • Door Control – Open/close doors remotely, timed open with server-side timing
  • Real-time Synchronization – Hybrid sync with SignalR real-time events (<500ms latency) + API polling fallback
  • SignalR Auto-Reconnect – Automatic reconnection with exponential backoff after Net2 server restart or network outage (new in v5.2.1)
  • Status Monitoring – Live door lock/unlock status via SignalR doorRelayOpen events
  • Access Logging – Track last user and access time per door, JSON-formatted entry events
  • Access Denied Detection – Real-time alerts for unauthorized access attempts (invalid cards/tokens)
  • User Management – Create/delete users and assign access levels from the bridge
  • Building Lockdown – Enable/disable lockdown across all configured doors
  • Activity Report – Auto-generated HTML report showing last 24h of access events, embeddable in sitemaps
  • Entry Log Dashboard – JSON entry events ready for InfluxDB persistence and Grafana visualization
  • Multi-Door Support – Control multiple doors from a single Net2 server
  • Token Management – Automatic JWT token refresh (30-min tokens)
  • Self-signed SSL – Works with Net2 self-signed certificates

Requirements

  • Paxton Net2 6.6 SR5 or newer
  • Net2 Local API enabled and licensed
  • Valid API client credentials (OAuth2)
  • Paxton Net2 Plus ACU or Net2 Classic ACU (Nano/Paxlock not supported)

Supported Things

Thing Type Description
net2server (Bridge) Connection to Net2 server via REST API + SignalR
door Individual door with relay control and status

Channels

Door Channels

Channel Type R/W Description
status Switch RO Door relay physical status (ON=Open, OFF=Closed) – real-time via SignalR
action Switch RW Control door (ON=Hold Open, OFF=Close)
controlTimed Number RW Timed open in seconds (server-side timing)
lastAccessUser String RO Last user who accessed the door
lastAccessTime DateTime RO Timestamp of last door access
entryLog String RO JSON entry event (physical badge access only)
accessDenied String RO JSON access denied event (invalid card/token)

Bridge Channels

Channel Type R/W Description
createUser String WO Create user: firstName,lastName,accessLevel,pin
deleteUser String WO Delete user by ID
listAccessLevels String WO Query and log all access levels
listUsers String WO Query and log all users as JSON
lockdown Switch RW Building lockdown (ON=enable, OFF=disable)
activityReport String RO Last report update timestamp

Quick Start

net2.things

Bridge net2:net2server:myserver [
    hostname="net2.example.com",
    port=8443,
    username="John Doe",
    password="your_secure_password",
    clientId="your_oauth_client_id",
    tlsVerification=false,
    refreshInterval=600
] {
    Thing door frontdoor  [doorId=6203980, name="Front Door"]
    Thing door backdoor   [doorId=6203981, name="Back Door"]
    Thing door garage     [doorId=6203982, name="Garage"]
}

net2.items

Group gNet2 "Access Control" <lock>

// Front Door
Switch Front_Door_Lock     "Front Door"           <lock>     (gNet2) { channel="net2:door:myserver:frontdoor:action" }
Switch Front_Door_Status   "Front Door Status"     <door>     (gNet2) { channel="net2:door:myserver:frontdoor:status" }
String Front_Door_LastUser "Last Access [%s]"                 (gNet2) { channel="net2:door:myserver:frontdoor:lastAccessUser" }
DateTime Front_Door_LastTime "Last Time [%1$td.%1$tm.%1$tY %1$tH:%1$tM]" (gNet2) { channel="net2:door:myserver:frontdoor:lastAccessTime" }
String Front_Door_EntryLog "Entry Log [%s]"                   (gNet2) { channel="net2:door:myserver:frontdoor:entryLog" }
String Front_Door_Denied   "Access Denied [%s]"               (gNet2) { channel="net2:door:myserver:frontdoor:accessDenied" }

// Bridge - User Management
String Net2_CreateUser       "Create User"       { channel="net2:net2server:myserver:createUser" }
String Net2_DeleteUser       "Delete User"       { channel="net2:net2server:myserver:deleteUser" }
Switch Net2_Lockdown         "Building Lockdown"  { channel="net2:net2server:myserver:lockdown" }

Rules Example

rule "Door Opened"
when
    Item Front_Door_Status changed to ON
then
    logInfo("Door", "Front door has been opened")
end

rule "Access Denied Alert"
when
    Item Front_Door_Denied received update
then
    logWarn("Security", "Unauthorized access attempt: {}", Front_Door_Denied.state)
    sendNotification("admin@example.com", "Access denied at Front Door!")
end

rule "Create User"
when
    Item CreateUser_Button received command ON
then
    Net2_CreateUser.sendCommand("Michael,Agesen,3,7654")
end

Activity Report

The binding auto-generates an HTML report at /static/net2_activity.html:

Webview url="/static/net2_activity.html" height=100

Real-time Synchronization

The binding uses a hybrid approach:

Method Latency Purpose
SignalR WebSocket <500ms Instant door state changes via DoorStatusEvents
API Polling 10 min (configurable) Backup synchronization fallback

SignalR subscribes to DoorStatusEvents (door relay open/close) and LiveEvents (access granted/denied events).

Auto-Reconnect (v5.2.1): If the Net2 server restarts or a network outage occurs, the binding automatically reconnects SignalR with exponential backoff (30s, 60s, 120s, 240s, 300s cap). All door subscriptions are re-established after reconnect. The API polling cycle also acts as a safety-net: if it detects SignalR is down with no reconnect scheduled, it triggers one immediately.
