NOTE: Ensure that the Bluetooth binding is installed on your system as well, or the binding will not start
Bluetooth binding for any BTHome device. Examples include
.. and more.
Latest OH jars can be found here
Take a look at https://bthome.io/ for more information.
The binding is mostly complete with just encryption support missing.
To see what’s happening, read the commit log
Arne
Update: Added datatypes used by all Shelly BLU products
First thanks for this binding. I’m seeing odd behaviour with thing channels using it though (4.1.0 snapshot) on openhab 5.2. I have 10 or so ATC Mithermometers and a couple of esp32 bluetooth proxies, some work ok others keep changing available channels. The channels detected switch between temp, humidity and battery like this (when working ok):
UID: bluetooth:bthome:proxy:ATCbasement
label: BTHome basement thermometer
thingTypeUID: bluetooth:bthome
configuration:
expectedReportingIntervalSeconds: 1200
address: A4:C1:38:05:76:16
bridgeUID: bluetooth:esphome:proxy
channels:
- id: humidity
channelTypeUID: bluetooth:bthome-ATCbasement-humidity
label: Humidity
configuration: {}
- id: temperature
channelTypeUID: bluetooth:bthome-ATCbasement-temperature
label: Temperature
configuration: {}
- id: packet-id
channelTypeUID: bluetooth:bthome-ATCbasement-packet-id
label: Packet-id
configuration: {}
- id: battery
channelTypeUID: bluetooth:bthome-ATCbasement-battery
label: Battery
configuration: {}
and the following for the same device when not working:
UID: bluetooth:bthome:proxy:ATCbasement
label: BTHome basement thermometer
thingTypeUID: bluetooth:bthome
configuration:
expectedReportingIntervalSeconds: 1200
address: A4:C1:38:05:76:16
bridgeUID: bluetooth:esphome:proxy
channels:
- id: opening
channelTypeUID: bluetooth:bthome-ATCbasement-opening
label: Opening
configuration: {}
- id: voltage
channelTypeUID: bluetooth:bthome-ATCbasement-voltage
label: Voltage
configuration: {}
- id: power-on
channelTypeUID: bluetooth:bthome-ATCbasement-power-on
label: Power-on
configuration: {}
- id: packet-id
channelTypeUID: bluetooth:bthome-ATCbasement-packet-id
label: Packet-id
configuration: {}
Is there any way to prevent this? I have tried coding the channels I want in bthome.things below but that doesn’t do it:
bthome ATCbasement "BTHome basement thermometer" [ address="A4:C1:38:05:76:16", expectedReportingIntervalSeconds = 1200]{
Channels:
Type bthome-ATCbasement-temperature : temperature "Temperature" [pattern="%.1f °C"]
Type bthome-ATCbasement-humidity : humidity "Humidity"
Type bthome-ATCbasement-battery : battery "Battery"
}
Funky.
Initial guess; the data is somehow corrupted - either coming from the device itself or somewhere along the data path (device → proxy → esphome binding → bthome binding).
If you could try to capture TRACE level logs for both the bthome and esphome binding around the time a device changes channels, that might be a clue where it goes wrong.
BRG
here are a couple of extracts from the trace log of things going wrong and right (should i attach this)
2025-11-15 11:06:24.958 [DEBUG] [uetooth.ESPHomeBluetoothProxyHandler] - Received duplicate BLE advertisement from device 202844586484103 via esphome:device:4d3ab917fe
2025-11-15 11:06:25.002 [TRACE] [ome.internal.comm.ConnectionSelector] - Num selected keys: 1
2025-11-15 11:06:25.002 [TRACE] [ome.internal.comm.ConnectionSelector] - Processing key readable=true, connectable=false
2025-11-15 11:06:25.002 [TRACE] [ome.internal.comm.ConnectionSelector] - Received data
2025-11-15 11:06:25.002 [TRACE] [e.internal.comm.EncryptedFrameHelper] - [esphomeupstairs] Received packet of type 93 with data [10, 30, 8, -16, -18, -35, -61, -109, -104, 41, 16, -87, 1, 34, 17, 2, 1, 6, 13, 22, -46, -4, 64, 0, 64, 12, -47, 11, 16, 0, 17, 1, 10, 37, 8, -121, -61, -106, -4, -58, -113, 46, 16, -77, 1, 34, 24, 2, 1, 6, 20, 22, -107, -2, 113, 32, 19, 1, 125, -121, -95, -123, 111, 124, -72, 9, 5, 16, 2, 0, 20]
2025-11-15 11:06:25.002 [DEBUG] [home.internal.handler.ESPHomeHandler] - [esphomeupstairs] Received message type BluetoothLERawAdvertisementsResponse with content ‘advertisements {
address: 181149782996848
rssi: -85
data: “\002\001\006\r\026\322\374@\000@\f\321\v\020\000\021\001”
}
advertisements {
address: 202844586484103
rssi: -90
data: “\002\001\006\024\026\225\376q \023\001}\207\241\205o|\270\t\005\020\002\000\024”
}’
2025-11-15 11:06:25.002 [DEBUG] [uetooth.ESPHomeBluetoothProxyHandler] - Received BLE advertisement from device A4:C1:38:77:77:70/181149782996848 via esphome:device:esphomeupstairs
2025-11-15 11:06:25.003 [DEBUG] [etooth.bthome.internal.BTHomeHandler] - Received updated BTHome data
2025-11-15 11:06:25.003 [DEBUG] [etooth.bthome.internal.BTHomeHandler] - Created new channel type bluetooth:bthome-ATCpotato-opening
2025-11-15 11:06:25.003 [DEBUG] [etooth.bthome.internal.BTHomeHandler] - Created new channel type bluetooth:bthome-ATCpotato-voltage
2025-11-15 11:06:25.003 [DEBUG] [etooth.bthome.internal.BTHomeHandler] - Created new channel type bluetooth:bthome-ATCpotato-power-on
2025-11-15 11:06:25.004 [DEBUG] [uetooth.ESPHomeBluetoothProxyHandler] - Received duplicate BLE advertisement from device 202844586484103 via esphome:device:esphomeupstairs
2025-11-15 11:06:25.361 [TRACE] [ome.internal.comm.ConnectionSelector] - Num selected keys: 1
2025-11-15 11:06:25.361 [TRACE] [ome.internal.comm.ConnectionSelector] - Processing key readable=true, connectable=false
2025-11-15 11:06:25.361 [TRACE] [ome.internal.comm.ConnectionSelector] - Received data
2025-11-15 11:06:25.361 [TRACE] [e.internal.comm.EncryptedFrameHelper] - [esphomeupstairs] Received packet of type 93 with data [10, 46, 8, -120, -4, -122, -30, -116, -30, 26, 16, -89, 1, 24, 1, 34, 31, 2, 1, 2, 3, 3, -97, -2, 23, 22, -97, -2, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0]
2025-11-15 11:06:25.362 [DEBUG] [home.internal.handler.ESPHomeHandler] - [esphomeupstairs] Received message type BluetoothLERawAdvertisementsResponse with content ‘advertisements {
address: 117719890509320
rssi: -84
address_type: 1
data: “\002\001\002\003\003\237\376\027\026\237\376\000\000\000\000\000\000\000\000\000\000\000\000\000\000\000\000\000\000\000\000”
}’
and again when it goes right
2025-11-15 11:07:27.617 [TRACE] [e.internal.comm.EncryptedFrameHelper] - [4d3ab917fe] Received packet of type 93 with data [10, 31, 8, -16, -18, -35, -61, -109, -104, 41, 16, -61, 1, 34, 18, 2, 1, 6, 14, 22, -46, -4, 64, 0, 70, 1, 100, 2, 76, 8, 3, -127, 20, 10, 46, 8, -52, -40, -89, -40, -76, -11, 12, 16, -87, 1, 24, 1, 34, 31, 30, -1, 6, 0, 1, 9, 32, 34, -126, 7, 78, -14, -122, -93, 78, 17, -73, -123, -55, 126, 73, 59, -42, 23, 7, 90, 109, -122, -17, -61, -48]
2025-11-15 11:07:27.617 [DEBUG] [home.internal.handler.ESPHomeHandler] - [4d3ab917fe] Received message type BluetoothLERawAdvertisementsResponse with content ‘advertisements {
address: 181149782996848
rssi: -98
data: “\002\001\006\016\026\322\374@\000F\001d\002L\b\003\201\024”
}
advertisements {
address: 56810791365708
rssi: -85
address_type: 1
data: “\036\377\006\000\001\t "\202\aN\362\206\243N\021\267\205\311~I;\326\027\aZm\206\357\303\320”
}’
2025-11-15 11:07:27.617 [DEBUG] [uetooth.ESPHomeBluetoothProxyHandler] - Received BLE advertisement from device A4:C1:38:77:77:70/181149782996848 via esphome:device:4d3ab917fe
2025-11-15 11:07:27.617 [DEBUG] [etooth.bthome.internal.BTHomeHandler] - Received updated BTHome data
2025-11-15 11:07:27.617 [DEBUG] [etooth.bthome.internal.BTHomeHandler] - Created new channel type bluetooth:bthome-ATCpotato-battery
2025-11-15 11:07:27.617 [DEBUG] [etooth.bthome.internal.BTHomeHandler] - Created new channel type bluetooth:bthome-ATCpotato-humidity
2025-11-15 11:07:27.618 [DEBUG] [etooth.bthome.internal.BTHomeHandler] - Created new channel type bluetooth:bthome-ATCpotato-temperature
2025-11-15 11:07:27.619 [DEBUG] [uetooth.ESPHomeBluetoothProxyHandler] - Received duplicate BLE advertisement from device 56810791365708 via esphome:device:4d3ab917fe
2025-11-15 11:07:27.620 [TRACE] [ome.internal.comm.ConnectionSelector] - Num selected keys: 1
2025-11-15 11:07:27.621 [TRACE] [ome.internal.comm.ConnectionSelector] - Processing key readable=true, connectable=false
2025-11-15 11:07:27.621 [TRACE] [ome.internal.comm.ConnectionSelector] - Received data
2025-11-15 11:07:27.621 [TRACE] [e.internal.comm.EncryptedFrameHelper] - [esphomeupstairs] Received packet of type 93 with data [10, 37, 8, -121, -61, -106, -4, -58, -113, 46, 16, -65, 1, 34, 24, 2, 1, 6, 20, 22, -107, -2, 113, 32, 19, 1, -121, -121, -95, -123, 111, 124, -72, 9, 5, 16, 2, 0, 20]
2025-11-15 11:07:27.621 [DEBUG] [home.internal.handler.ESPHomeHandler] - [esphomeupstairs] Received message type BluetoothLERawAdvertisementsResponse with content ‘advertisements {
address: 202844586484103
rssi: -96
data: “\002\001\006\024\026\225\376q \023\001\207\207\241\205o|\270\t\005\020\002\000\024”
}’
This device apparently sends 2 different packets
Instead of aggregating the channels (4 existing + 3 new), the existing channels were replaced with the new ones. The correct thing to do would to just aggregate the channels.
So after updating expect to find all 7 distinct channels on each thing.
Thanks for testing,
BRG
Thanks for the update! Now I’m seeing 7 (or 8 for one of them) channels for each device. I didn’t guess that the ATC firmware for the Xiaomi LYWSD03MMC was splitting the data despite it making sense to do so.
