Samsung SmartThings Cloud Binding (Beta) [5.0.0.0;6.0.0.0)

Nanna_Agesen · April 29, 2026, 5:55pm

Key	Value
uid	smartthingscloud
type	binding
author	Nanna Agesen
version range	[5.0.0;6.0.0)
download	org.openhab.binding.smartthingscloud-5.2.0-SNAPSHOT.jar

Samsung SmartThings Cloud Binding

Connect your Samsung SmartThings cloud-connected appliances to openHAB — no hub, no Personal Access Token, no developer registration required.

Authorization uses OAuth2 PKCE (the same flow as the official SmartThings CLI). You click Authorize in the browser on the openHAB machine, log in with your Samsung account, and the bridge goes ONLINE. Tokens are persisted and auto-refreshed — no re-authorization needed after restart.

Note: This is not the legacy SmartThings Hub binding. That binding required a physical SmartThings Hub and Groovy SmartApps, which Samsung deprecated in 2022. This binding communicates directly with the Samsung SmartThings Cloud API and works with any Wi-Fi connected Samsung appliance.

Supported Things

Thing Type	Description
`account` (Bridge)	Samsung SmartThings account — manages OAuth2 tokens
`washer`	Samsung washing machine
`television`	Samsung Smart TV
`presence`	SmartThings phone / presence sensor
`lightSensor`	SmartThings illuminance sensor
`scene`	SmartThings scene — trigger a scene with a Switch

Channels

Account Bridge — Status (read-only)

| Channel | Type | Description |
|----|----|----|—|
| authStatus | String | Authorization state: Authorized ✓ / Connection failed — check logs / Not authorized — open .../smartthingscloud |

Washer — State (read-only)

Channel	Type	Description
`machineState`	String	Machine state: `run`, `pause`, `stop`
`jobState`	String	Cycle phase: `washing`, `rinsing`, `spin`, `finish`, `none`, etc.
`completionTime`	DateTime	Estimated finish time
`running`	Switch	ON while a cycle is active
`remaining`	Number	Minutes remaining
`remoteEnabled`	Switch	ON when remote control is permitted by the machine
`mode`	String	Active wash program code
`rinseMode`	String	Rinse count/mode
`spinSpeed`	String	Spin speed (rpm)
`temperature`	String	Wash temperature (°C)
`watt`	Number:Power	Current power consumption (W)
`kwh`	Number:Energy	Accumulated energy usage (kWh)
`waterLiters`	Number	Cumulative water consumed (lifetime total, liters)
`operatingState`	String	Detailed operating state: `ready`, `running`, `paused`, `finished`
`currentCycle`	String	Active wash program code from Samsung (e.g. `B0`, `1B`, `65`)
`kidsLock`	Switch	ON when child lock is active
`progress`	Number	Wash cycle progress 0–100 % (only populated while running)
`detergentRemaining`	Number	Detergent level remaining (%)
`softenerRemaining`	Number	Softener level remaining (%)
`delayEnd`	Number	Delay-end countdown remaining (minutes)
`supportedCourses`	String	Comma-separated list of supported wash programs

Washer — Control (read/write)

Channel	Type	Description
`power`	Switch	Power on/off
`bubbleSoak`	Switch	Bubble Soak pre-soak on/off
`volume`	Number	End-of-cycle buzzer volume: 0=off, 1–3
`extraCare`	String	Extra Care mode (`off`, `manual`, `userLocationBased`)
`extraCareLocation`	String	Extra Care location (`indoor`, `outdoor`)

Washer — Energy totals (read-only)

Channel	Type	Description
`watt`	Number:Power	Live power consumption (W)
`kwh`	Number:Energy	Accumulated energy used (kWh)

Television — State (read-only)

| Channel | Type | Description |
|----|----|----|—|
| tvVolume | Number | Current volume level (0–100) |
| tvMute | Switch | ON when muted |
| inputSource | String | Active input source (e.g. HDMI1, digitalTv) |
| tvChannel | String | Active channel number |
| tvChannelName | String | Active channel name |
| pictureMode | String | Picture mode: Standard, Movie, Game, etc. |
| soundMode | String | Sound mode: Standard, Movie, Music, etc. |
| playbackStatus | String | Current playback state |
| watt | Number:Power | Current power draw (W) |
| kwh | Number:Energy | Accumulated energy (kWh, lifetime) |
| firmwareVersion | String | TV firmware version |
| onlineStatus | String | Online status (Idle, Active) |
| supportedInputSources | String | Comma-separated list of available input sources |
| supportedPictureModes | String | Comma-separated list of available picture modes |
| supportedSoundModes | String | Comma-separated list of available sound modes |

Television — Control (read/write)

| Channel | Type | Description |
|----|----|----|—|
| power | Switch | Power on/off |
| tvVolume | Number | Set volume (0–100) |
| tvMute | Switch | Mute/unmute |
| inputSource | String | Set input source |
| tvChannel | String | Set channel number |
| pictureMode | String | Set picture mode |
| soundMode | String | Set sound mode |
| channelUp | Switch | Zap one channel up (momentary — resets to OFF automatically) |
| channelDown | Switch | Zap one channel down (momentary — resets to OFF automatically) |

Presence — State (read-only)

Channel	Type	Description
`presence`	Switch	ON = home, OFF = away

Light Sensor — State (read-only)

Channel	Type	Description
`illuminance`	Number:Illuminance	Light level in lux
`brightnessLevel`	Dimmer	Brightness 0–100 % (maps lux to %)

Scene — Control (write-only)

| Channel | Type | Description |
|----|----|----||
| trigger | Switch | Send ON to execute the scene — auto-resets to OFF |

Configuration parameters:

Parameter	Required	Description
`sceneId`		SmartThings scene ID (UUID)
`locationId`		Location ID — only needed for multi-location accounts

Find your scene ID with the SmartThings CLI: smartthings scenes

Quick Start

smartthings.things

Bridge smartthingscloud:account:myaccount "Samsung SmartThings" [
    pollingIntervalSeconds=30
] {
    Thing washer mywasher "Samsung Washing Machine" [
        deviceId="xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx"
    ]
}

Tip: Find your deviceId in the Samsung SmartThings app under the device’s detail page, or it is shown on the authorization success page after the OAuth2 flow.

smartthings.items

Group gWasher "Washing Machine" <washingmachine>

// State
String          Washer_MachineState     "State [%s]"              (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:machineState" }
String          Washer_JobState         "Phase [%s]"              (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:jobState" }
Switch          Washer_Running          "Running"                 (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:running" }
Number          Washer_Remaining        "Remaining [%.0f min]"    (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:remaining" }
DateTime        Washer_CompletionTime   "Done at [%1$tH:%1$tM]"   (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:completionTime" }
Switch          Washer_RemoteEnabled    "Remote Control [%s]"     (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:remoteEnabled" }

// Program
String          Washer_Mode             "Program [%s]"            (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:mode" }
String          Washer_RinseMode        "Rinse [%s]"              (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:rinseMode" }
String          Washer_SpinSpeed        "Spin [%s rpm]"           (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:spinSpeed" }
String          Washer_Temperature      "Temperature [%s °C]"     (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:temperature" }

// Energy & water
Number:Power    Washer_Watt             "Power [%.0f W]"          (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:watt" }
Number:Energy   Washer_kWh              "Energy [%.2f kWh]"       (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:kwh" }
Number          Washer_WaterLiters      "Water [%.1f L]"          (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:waterLiters" }

// Extended state (read-only)
String          Washer_OperatingState   "Operating State [%s]"    (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:operatingState" }
String          Washer_CurrentCycle     "Active Program [%s]"     (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:currentCycle" }
Switch          Washer_KidsLock         "Child Lock [%s]"         (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:kidsLock" }
Number          Washer_Progress         "Progress [%.0f %%]"      (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:progress" }

// Control
Switch          Washer_Power            "Power"                   (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:power" }
Switch          Washer_BubbleSoak       "Bubble Soak"             (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:bubbleSoak" }
Number          Washer_Volume           "Volume [%.0f]"           (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:volume" }
String          Washer_ExtraCare        "Extra Care [%s]"         (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:extraCare" }
String          Washer_ExtraCareLocation "Location [%s]"          (gWasher) { channel="smartthingscloud:washer:myaccount:mywasher:extraCareLocation" }

Sitemap tip: Use mappings=[ON="On", OFF="Off"] (uppercase) for Switch channels in sitemaps. Lowercase keys send StringType instead of OnOffType and the command will be ignored.

OAuth2 Authorization

Add the bridge and washer things (.things file or UI)
Open http://localhost:8080/smartthingscloud in a browser on the openHAB machine itself
Click “Authorize with SmartThings” and log in with your Samsung account
Bridge goes ONLINE — done

Important: The browser must run on the same machine as openHAB. Samsung’s OAuth2 callback is hardcoded to http://localhost:61973/finish (a Samsung-side constraint from the SmartThings CLI client ID — it cannot be changed). Use SSH port forwarding (ssh -L 8080:localhost:8080 user@openhab-host) if you only have remote access.

Why no PAT token?

The binding reuses the clientId from the open-source SmartThings CLI — a client ID registered by Samsung for personal use that supports the standard OAuth2 PKCE flow. No developer account, no app registration, no secrets to manage.

Beta — contributions welcome!

This is a beta release. The following thing types are currently implemented:

washer — Samsung washing machine (26 channels)
television — Samsung Smart TV (12 channels — power, volume, mute, input, channel, picture/sound mode, app ID, channel up/down, supported inputs/modes)
presence — SmartThings phone / arrival sensor
lightSensor — illuminance (lux) + brightness level
scene — execute any SmartThings scene via a Switch channel

Still planned:

Dryer
Dishwasher
Air purifier / air conditioner
Fridge / freezer

If you own one of these and want openHAB support, I’d love to hear from you. Open an issue on GitHub describing your device and I’m happy to work with you to implement it — you don’t need Java experience, just the ability to test on your own device.

Resources

Download JAR: org.openhab.binding.smartthingscloud-5.2.0-SNAPSHOT.jar
Source Code: github.com/Prinsessen/openhab-smartthings-binding
Full Documentation: README.md
Release: v1.5.0 — Scene Support
License: EPL-2.0

Tested on openHAB 5.2. Feedback on openHAB 4.x compatibility welcome.
