<?xml version="1.0" encoding="UTF-8"?>
<thing:thing-descriptions bindingId="zwave"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:thing="https://openhab.org/schemas/thing-description/v1.0.0"
xsi:schemaLocation="https://openhab.org/schemas/thing-description/v1.0.0
https://openhab.org/schemas/thing-description/v1.0.0">
<thing-type id="shelly_wave2pm_00_000" listed="false">
<label>Wave 2PM Z-Wave™ smart switch, 2 channels 16 A total current (18 A peak), with power metering</label>
<description><![CDATA[
Z-Wave™ smart switch, 2 channels 16 A total current (18 A peak), with power metering<br /> <h1>Overview</h1><p>Remotely control two independent electrical appliances (e.g. lights) and monitor their power consumption separately and in total.</p><ul><li>2 channels (2x 10 A, 16 A total)</li><li>Power metering on each channel and in total</li><li>Extremely low power consumption: 0.3 W.</li><li>Z-Wave frequency band: 868.4 MHz (CEPT countries)</li><li>Latest technology: Z-Wave 800 Series</li><li>Automatic set-up with SmartStart </li><li>Security 2 Authenticated for the highest level of security</li><li>Supports over-the-air firmware updates</li><li>Simple installation in most standard electrical boxes and switches</li><li>Works with Z-Wave certified gateways and over 4,000 Z-Wave devices</li></ul><p>*A gateway (smart hub) is not included. A gateway (smart hub) is required for the configuration of the device.</p> <br /> <h2>Inclusion Information</h2><p>SmartStart adding (inclusion)</p><p>SmartStart enabled products can be added into a Z-Wave™ network by scanning the Z-Wave™ QR Code present on the Device with a gateway providing SmartStart inclusion. No further action is required, and the SmartStart device will be added automatically within 10 minutes of being switched on in the network vicinity.</p><ol><li>With the gateway application scan the QR code on the Device label and add the Security 2 (S2) Device Specific Key (DSK) to the provisioning list in the gateway.</li><li>Connect the Device to a power supply.</li><li>Check if the blue LED is blinking slowly. If so, the Device is not added to a Z-Wave™ network.</li><li>Adding will be initiated automatically within a few seconds after connecting the Device to a power supply, and the Device will be added to a Z-Wave™ network automatically.</li><li>The blue LED will be blinking faster during the adding process.</li><li>The green LED will be blinking in slowly if the Device is successfully added to a Z-Wave™ network.</li></ol><p>Adding (inclusion) with the S button</p><ol><li>Connect the Device to a power supply.</li><li>Check if the blue LED is blinking slowly. If so, the Device is not added to a Z-Wave™ network.</li><li>Enable add/remove mode on the gateway.</li><li>To enter the Setting mode, quickly press and hold the S button on the Device until the LED turns solid blue.</li><li>Quickly release and then press and hold (> 2s) the S button on the Device until the blue LED starts blinking slowly. Releasing the S button will start the Learn mode.</li><li>The blue LED will be blinking faster during the adding process.</li><li>The green LED will be blinking slowly if the Device is successfully added to a Z-Wave™ network.</li></ol><p>Note! In Setting mode, the Device has a timeout of 10s before entering again into Normal mode.</p><p>Adding (inclusion) with a switch/push-button</p><ol><li>Connect the Device to a power supply.</li><li>Check if the blue LED is blinking slowly. If so, the Device is not added to a Z-Wave™ network.</li><li>Enable add/remove mode on the gateway.</li><li>Toggle the switch/push-button connected to any of the SW terminals (SW, SW1, SW2, etc.) 3 times within 3 seconds (this procedure puts the Device in Learn mode*). The Device must receive on/off signal 3 times, which means pressing the momentary switch 3 times, or toggling the switch on and off 3 times.</li><li>The blue LED will be blinking faster during the adding process.</li><li>The green LED will be blinking slowly if the Device is successfully added to a Z-Wave™ network.</li></ol><p>*Learn mode - a state that allows the Device to receive network information from the gateway.</p> <br /> <h2>Exclusion Information</h2><p>Removing the Device from a Z-Wave™ network (exclusion)</p><p>Note! The Device will be removed from your Z-wave™ network, but any custom configuration parameters will not be erased.</p><p>Note! All Device outputs (O, O1, O2, etc. - depending on the Device type) will turn the load 1s on/1s off /1s on/1s off if the Device is successfully added to/removed from a Z-Wave™ network.</p><p>Removing (exclusion) with the S button</p><ol><li>1. Connect the Device to a power supply.</li><li>2. Check if the green LED will be blinking slowly. If so, the Device is added to a Z-Wave™ network.</li><li>3. Enable add/remove mode on the gateway.</li><li>4. To enter the Setting mode, quickly press and hold the S button on the Device until the LED turn
