I want ask regarding size of my widget cards
Actually I can see, that on the screen I have 3 cards ( width of each is 33% of the screen), but height isn’t the same:
Height of each is also randomly changing if side panel is on or off.
So question is, if it’s possible set (or fix) aspect ration of the cards, to have stable size for all.
Thanks
You can set the height of the card using the height style.
You can also explicitly set the aspect ratio of a card using the aspect-ratio style. Just be aware that Safari was the last to really implement this, so if you have older iOS devices they may not respect that setting, but any up to date iOS should be fine.
OK, If I will use height: 370px, widget height will stay fixed - doesn’t make sense which resolution has a display.
Much better looks aspect-ration : 1.8. Only small problem is, that white space is inserted (to keep ratio) always down of the card. So widget isn’t centered on the card.
If you want to center the card’s content, the easiest method is probably to change the card to a flexbox and set the alignment that way by adding:
display: flex
align-items: center
justify-content: center
to the card style.
So I added into card style this :
display: flex
align-items: center
justify-content: center
aspect-ratio: 1.7
now it’s ok.
thanks
let me ask one more question.
I’m using weather widget :
uid: Weather_Card
tags: []
props:
parameters:
- description: <b>Optional prefix</b> for item names
label: Item prefix
name: itemPrefix
required: false
type: TEXT
groupName: general
- description: <b>Additional prefix</b> for item names that belongs to another Things channel (valid for 'StationName' as it might differ)
label: Additional item prefix
name: itemPrefix2
required: false
type: TEXT
groupName: general
- description: The number of hours you want to forecast (<u>default:</u> <b>12</b>)
label: Number of hours to forecast
name: forecastHours
required: false
type: TEXT
groupName: general
- description: The number of days you want to forecast (<u>default:</u> <b>3</b>)
label: Number of days to forecast
name: forecastDays
required: false
type: TEXT
groupName: general
- description: Set a background-image which will be shown during the day (if empty it will fall back to the linear-gradient)
label: Background image-url (day-cycle)
name: backgroundUrlDay
required: false
type: TEXT
groupName: lookandfeel
- description: Set a background-image which will be shown during the night (if empty it will fall back to the linear-gradient)
label: Background image-url (night-cycle)
name: backgroundUrlNight
required: false
type: TEXT
groupName: lookandfeel
- description: Activate day & night Indication on hourly forecast (background color & sunrise / sunset indicator icon)
label: Show sunrise & sunset
name: sunIndicator
required: false
type: BOOLEAN
groupName: lookandfeel
- description: Overwrite the global font-color as rgb (<u>default:</u> <b>255,255,255<b>)
label: Font color (rgb)
name: fontColor
required: false
type: TEXT
groupName: lookandfeel
- description: Overwrite the global text shadow color as rgb (<u>default:</u> <b>0,0,0<b>)
label: Text shadow color(rgb)
name: textShadowColor
required: false
type: TEXT
groupName: lookandfeel
- label: Daytime background indication color
name: sunIndicatorColorDay
required: false
type: TEXT
groupName: lookandfeel
advanced: true
- label: Nighttime background indication color
name: sunIndicatorColorNight
required: false
type: TEXT
groupName: lookandfeel
advanced: true
- description: Overwrite the station location name
label: Location title
name: locationTitle
required: false
type: TEXT
groupName: localization
- description: Format of the timestamp below the location-name (<u>default:</u> <b>DD. MMMM YYYY</b>)<br>Visit <a 'https://day.js.org/docs/en/display/format'>https://day.js.org/docs/en/display/format</a> for more informations.
label: Timestamp format
name: dateScheme
required: false
type: TEXT
groupName: localization
- description: Acitvate 24-hour time-format (<u>default:</u> <b>12-hour clock-format</b>)
label: 24h hour-format
name: dateFormat
required: false
type: BOOLEAN
groupName: localization
- description: Add suffix to the hourly-forecast timestamp
label: Custom hour suffix
name: timestampSuffix
required: false
type: TEXT
groupName: localization
- label: Translation 'Feel'
name: wordingFeel
required: false
type: TEXT
groupName: localization
- label: Translation 'Hourly'
name: wordingForecastHours
required: false
type: TEXT
groupName: localization
- label: Translation 'Daily'
name: wordingForecastDays
required: false
type: TEXT
groupName: localization
- label: Translation '%-Precipitation'
name: wordingForecastPrecib
required: false
type: TEXT
groupName: localization
- label: Translation 'Now'
name: wordingNow
required: false
type: TEXT
groupName: localization
- label: Translation 'Today'
name: wordingToday
required: false
type: TEXT
groupName: localization
- label: Translation 'Sunrise at'
name: wordingSunrise
required: false
type: TEXT
groupName: localization
- label: Translation 'Sunset at'
name: wordingSunset
required: false
type: TEXT
groupName: localization
parameterGroups:
- name: general
label: General settings
- name: lookandfeel
label: Look & Feel
description: Everything that influences the look & feel of the widget
- name: localization
label: Localization settings
description: Set alternative wordings & date pattern
timestamp: May 10, 2024, 8:21:32 PM
component: f7-card
config:
style:
aspect-ratio: 1.7
--weather-card-text-color: rgba(var(--weather-card-color),1)
--weather-font-size-date: =(device.desktop)?('0.8vw'):('3vw')
--weather-font-size-descr: =(device.desktop)?('1.1vw'):('4vw')
--weather-font-size-feel: =(device.desktop)?('1.0vw'):('3vw')
--weather-font-size-hum-wind: =(device.desktop)?('0.8vw'):('3vw')
--weather-font-size-icon: =(device.desktop)?('3vw'):('12vw')
--weather-font-size-slider-text: =(device.desktop)?('0.8vw'):('2.5vw')
--weather-font-size-slider-text-temp-max-min-pr: =(device.desktop)?('0.9vw'):('3vw')
--weather-font-size-temper: =(device.desktop)?('2.5vw'):('8vw')
--weather-font-size-title: =(device.desktop)?('1.3vw'):('4vw')
--weather-icon-size-slider: =(device.desktop)?('1.5vw'):('7vw')
--weather-text-transform-time: uppercase
border-radius: var(--f7-card-expandable-border-radius)
box-shadow: 5px 5px 10px 1px rgba(0,0,0,0.3)
color: var(--weather-card-text-color)
margin-left: 5px
margin-right: 5px
noShadow: false
padding: 0px
slots:
content:
- component: f7-block
config:
style:
background: "=dayjs().format() >= items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'ForecastToday_Sunrise'].state && dayjs().format() < items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'ForecastToday_Sunset'].state ? 'no-repeat 100% / cover url(' + props.backgroundUrlDay + ')' : 'no-repeat 100% / cover url(' + props.backgroundUrlNight + ')'"
margin: 0
padding: 0
slots:
default:
- component: f7-row
slots:
default:
- component: f7-col
config:
class:
- text-align-center
style:
width: 40%
slots:
default:
- component: Label
config:
style:
font-size: var(--weather-font-size-title)
font-weight: 600
letter-spacing: .75px
overflow: hidden
text-overflow: ellipsis
white-space: nowrap
text: "=!props.locationTitle ? items[(!props.itemPrefix2 ? (!props.itemPrefix ? '' : props.itemPrefix) : props.itemPrefix2) + 'StationName'].state : props.locationTitle"
- component: f7-icon
config:
f7: "=(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '01d') ? 'sun_max_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '01n') ? 'moon_stars_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '02d') ? 'cloud_sun_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '02n') ? 'cloud_moon_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '03d') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '03n') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '04d') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '04n') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '09d') ? 'cloud_heavyrain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '09n') ? 'cloud_heavyrain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '10d') ? 'cloud_sun_rain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '10n') ? 'cloud_moon_rain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '11d') ? 'cloud_sun_bolt_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '11n') ? 'cloud_moon_bolt_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '13d') ? 'cloud_snow_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '13n') ? 'cloud_snow_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '50d') ? 'cloud_fog_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_IconId'].state === '50n') ? 'cloud_fog_fill' : '?'"
style:
font-size: var(--weather-font-size-icon)
- component: Label
config:
style:
font-size: var(--weather-font-size-descr)
overflow: hidden
text-overflow: ellipsis
white-space: nowrap
text: "=items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_Weather_Condition'].state"
- component: f7-col
config:
style:
width: 20%
- component: f7-col
config:
style:
align-self: center
width: 40%
slots:
default:
- component: Label
config:
style:
font-size: var(--weather-font-size-temper)
font-weight: 600
line-height: var(--weather-font-size-temper)
overflow: hidden
text-align: center
text-overflow: ellipsis
white-space: nowrap
text: "=Math.round(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_Temperature'].state.split(' ')[0] * 10) / 10 + '°'"
- component: Label
config:
style:
font-size: var(--weather-font-size-feel)
overflow: hidden
text-align: center
text-overflow: ellipsis
white-space: nowrap
text: "=((!props.wordingFeel) ? 'Feel: ' : props.wordingFeel + ': ') + Math.round(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_Apparent_Temperature'].state.split(' ')[0]) + '°'"
- component: f7-row
config:
style:
font-size: var(--weather-font-size-hum-wind)
slots:
default:
- component: f7-col
config:
style:
width: 38%
slots:
default:
- component: Label
config:
style:
overflow: hidden
text-align: right
text-overflow: ellipsis
white-space: nowrap
text: "=Math.round(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_Humidity'].state.split('.')[1]) + ' %'"
tooltip: Humidity
- component: f7-col
config:
style:
width: 10%
slots:
default:
- component: Label
config:
style:
color: rgba(var(--weather-card-color),.25)
text-align: center
text: =" | "
- component: f7-col
config:
style:
width: 52%
slots:
default:
- component: Label
config:
style:
overflow: hidden
text-align: left
text-overflow: ellipsis
white-space: nowrap
text: "=Math.round(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_Windspeed'].state.split(' ')[0]) + ' ' + items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Current_Windspeed'].state.split(' ')[1]"
tooltip: Windspeed
- component: f7-block
config:
class:
- no-padding
- no-margin
- align-items-space-between
slots:
default:
- component: f7-segmented
config:
strong: true
style:
--f7-button-active-text-color: rgba(var(--weather-card-color),1)
--f7-button-border-radius: 0
--f7-button-raised-box-shadow: none
--f7-button-text-color: rgba(var(--weather-card-color),.5)
--f7-segmented-strong-button-active-bg-color: transparent
--f7-segmented-strong-button-active-box-shadow: 0px 4px 0 -1px rgba(var(--weather-card-color),1)
--f7-segmented-strong-button-active-text-color: rgba(var(--weather-card-color),1)
--f7-segmented-strong-padding: 3px
--f7-segmented-strong-text-color: rgba(var(--weather-card-color),.5)
align-items: flex-end
background: transparent
padding-top: 2%
width: =calc(100% - 38px)
textColor: white
slots:
default:
- component: oh-button
config:
action: variable
actionVariable: tab
actionVariableValue: hourly_forecast
active: =vars.tab === 'hourly_forecast'
color: var(--weather-card-text-color)
style:
--f7-button-font-size: =(device.desktop)?('0.8vw'):('2.5vw')
height: =(device.desktop)?('1.8vw'):('7vw')
text: "=(!props.wordingForecastHours) ? 'Hourly' : props.wordingForecastHours"
- component: oh-button
config:
action: variable
actionVariable: tab
actionVariableValue: daily_forecast
active: =vars.tab === 'daily_forecast'
color: var(--weather-card-text-color)
style:
--f7-button-font-size: =(device.desktop)?('0.8vw'):('2.5vw')
height: =(device.desktop)?('1.8vw'):('7vw')
text: "=(!props.wordingForecastDays) ? 'Daily' : props.wordingForecastDays"
- component: oh-button
config:
action: variable
actionVariable: tab
actionVariableValue: precip_forecast
active: =vars.tab === 'precip_forecast'
color: var(--weather-card-text-color)
style:
--f7-button-font-size: =(device.desktop)?('0.8vw'):('2.5vw')
height: =(device.desktop)?('1.8vw'):('7vw')
text: "=(!props.wordingForecastPrecib) ? '%-Precipitation' : props.wordingForecastPrecib"
- component: f7-block
config: {}
- component: f7-swiper
config:
navigation: true
params:
breakpoints:
"0":
slidesPerView: 1
"240":
slidesPerView: 2
"320":
slidesPerView: 4
"480":
slidesPerView: 5
"640":
slidesPerView: 5
grabCursor: true
initalSlide: 0
keyboard: true
mousewheel: true
observeSlideChildren: true
observer: true
runCallbacksOnInit: true
spaceBetween: 0
updateOnWindowResize: true
watchOverflow: true
style:
width: 100%
--swiper-navigation-color: var(--weather-card-text-color)
--swiper-navigation-size: 30px
visible: =vars.tab === 'hourly_forecast' || !vars.tab
slots:
default:
- component: oh-repeater
config:
for: hour
fragment: true
rangeStart: 0
rangeStop: "=(!props.forecastHours) ? 12 : Number(props.forecastHours)"
sourceType: range
slots:
default:
- component: f7-swiper-slide
config:
expandable: true
style:
background: "=(props.sunIndicator) ? ((dayjs().add(loop.hour,'hour').format() >= items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunrise'].state && dayjs().add(loop.hour,'hour').format() <= items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunset'].state) ? (!props.sunIndicatorColorDay ? 'rgba(255,255,255,.2)' : props.sunIndicatorColorDay) : (!props.sunIndicatorColorNight ? 'rgba(41,109,152,.2)' : props.sunIndicatorColorNight)) : 'none'"
border-radius: 5px
slots:
default:
- component: f7-icon
config:
f7: sun_max_fill
size: 17px
style:
color: var(--weather-card-text-color)
cursor: pointer
position: absolute
right: 3px
top: 3px
z-index: 998
tooltip: "=((!props.wordingSunrise) ? 'Sunrise at ' : props.wordingSunrise + ' ') + ((!props.dateFormat) ? dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunrise'].state).format('h:mm A') : dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunrise'].state).format('H:mm') + (!props.timestampSuffix ? '' : ' ' + props.timestampSuffix) ) + '<br><b>' + dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunrise'].state).fromNow() + '</b>'"
visible: "=(dayjs().add(loop.hour,'hour').startOf('hour').format() === dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunrise'].state).startOf('hour').format() && props.sunIndicator === true)"
- component: f7-icon
config:
f7: moon_fill
size: 17px
style:
color: var(--weather-card-text-color)
cursor: pointer
position: absolute
right: 3px
top: 3px
z-index: 998
tooltip: "=((!props.wordingSunset) ? 'Sunset at ' : props.wordingSunset + ' ') + ((!props.dateFormat) ? dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunset'].state).format('h:mm A') : dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunset'].state).format('H:mm') + (!props.timestampSuffix ? '' : ' ' + props.timestampSuffix) ) + '<br><b>' + dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunset'].state).fromNow() + '</b>'"
visible: "=(dayjs().add(loop.hour,'hour').startOf('hour').format() === dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunset'].state).startOf('hour').format() && props.sunIndicator === true)"
- component: f7-row
config:
class:
- justify-content-center
slots:
default:
- component: Label
config:
style:
color: var(--weather-card-text-color)
font-size: var(--weather-font-size-slider-text)
font-weight: 700
text-transform: var(--weather-text-transform-time)
text: "=(loop.hour === 0) ? ((!props.wordingNow) ? 'Now' : props.wordingNow) : ((!props.dateFormat) ? dayjs().add(loop.hour,'hour').startOf('hour').format('h A') : dayjs().add(loop.hour,'hour').startOf('hour').format('H')) + (!props.timestampSuffix ? '' : ' ' + props.timestampSuffix)"
- component: f7-col
config:
class:
- text-align-center
slots:
default:
- component: f7-icon
config:
f7: "=(items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '01d') ? 'sun_max_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '01n') ? 'moon_stars_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '02d') ? 'cloud_sun_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '02n') ? 'cloud_moon_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '03d') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '03n') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '04d') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '04n') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '09d') ? 'cloud_heavyrain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '09n') ? 'cloud_heavyrain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '10d') ? 'cloud_sun_rain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '10n') ? 'cloud_moon_rain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '11d') ? 'cloud_sun_bolt_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '11n') ? 'cloud_moon_bolt_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '13d') ? 'cloud_snow_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '13n') ? 'cloud_snow_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '50d') ? 'cloud_fog_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_IconId'].state === '50n') ? 'cloud_fog_fill' : '?'"
size: var(--weather-icon-size-slider)
style:
color: var(--weather-card-text-color)
padding-bottom: 0px
padding-top: 0px
- component: Label
config:
style:
color: var(--weather-card-text-color)
font-size: var(--weather-font-size-slider-text-temp-max-min-pr)
font-weight: 400
text: "=Math.round(items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current' : 'ForecastHours_' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_Temperature'].state.split(' ')[0]) + '°'"
- component: f7-swiper
config:
navigation: true
params:
breakpoints:
"0":
slidesPerView: 1
"210":
slidesPerView: "=(!props.forecastDays) ? 4 : ((props.forecastDays < 2) ? Math.round(Number(props.forecastDays) + 1) : 2)"
"480":
slidesPerView: "=(!props.forecastDays) ? 4 : ((props.forecastDays < 3) ? Math.round(Number(props.forecastDays) + 1) : 3)"
"640":
slidesPerView: "=(!props.forecastDays) ? 4 : ((props.forecastDays < 4) ? Math.round(Number(props.forecastDays) + 1) : 4)"
grabCursor: true
initalSlide: 0
keyboard: true
mousewheel: true
observeSlideChildren: true
observer: true
spaceBetween: 0
updateOnWindowResize: true
watchOverflow: true
style:
--swiper-navigation-color: var(--weather-card-text-color)
--swiper-navigation-size: 30px
visible: =vars.tab === 'daily_forecast'
slots:
default:
- component: oh-repeater
config:
for: day
fragment: true
rangeStart: 0
rangeStop: "=(!props.forecastDays) ? 3 : Number(props.forecastDays)"
sourceType: range
slots:
default:
- component: f7-swiper-slide
config:
class: text-align-center
slots:
default:
- component: f7-row
config:
class:
- justify-content-center
- align-items-center
slots:
default:
- component: Label
config:
style:
color: var(--weather-card-text-color)
font-size: var(--weather-font-size-slider-text)
font-weight: 700
text-transform: var(--weather-text-transform-time)
text: "=(loop.day === 0) ? ((!props.wordingToday) ? 'Today' : props.wordingToday) : dayjs().add(loop.day,'day').startOf('day').format('dddd')"
- component: f7-icon
config:
f7: "=(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '01d') ? 'sun_max_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '01n') ? 'moon_stars_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '02d') ? 'cloud_sun_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '02n') ? 'cloud_moon_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '03d') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '03n') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '04d') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '04n') ? 'cloud_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '09d') ? 'cloud_heavyrain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '09n') ? 'cloud_heavyrain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '10d') ? 'cloud_sun_rain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '10n') ? 'cloud_moon_rain_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '11d') ? 'cloud_sun_bolt_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '11n') ? 'cloud_moon_bolt_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '13d') ? 'cloud_snow_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '13n') ? 'cloud_snow_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '50d') ? 'cloud_fog_fill' : (items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + loop.day_idx))) + '_IconId'].state === '50n') ? 'cloud_fog_fill' : '?'"
size: var(--weather-icon-size-slider)
style:
color: var(--weather-card-text-color)
padding-bottom: 5px
padding-top: 5px
- component: f7-row
config:
class:
- justify-content-center
slots:
default:
- component: Label
config:
style:
color: var(--weather-card-text-color)
font-size: var(--weather-font-size-slider-text-temp-max-min-pr)
font-weight: 400
text: "=Math.round(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast_' + ((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + (loop.day_idx))) + '_Maxtemperature'].state.split(' ')[0])+'°'"
- component: Label
config:
style:
color: var(--weather-card-text-color)
font-size: var(--weather-font-size-slider-text-temp-max-min-pr)
text: =" | "
- component: Label
config:
style:
color: var(--weather-card-text-color)
font-size: var(--weather-font-size-slider-text-temp-max-min-pr)
font-weight: 400
text: "=Math.round(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast_' + ((loop.day === 0) ? 'Today' : ((loop.day === 1) ? 'Tomorrow' : 'Day' + (loop.day_idx))) + '_Mintemperature'].state.split(' ')[0])+'°'"
- component: f7-swiper
config:
navigation: true
params:
breakpoints:
"0":
slidesPerView: 1
"240":
slidesPerView: 2
"320":
slidesPerView: 4
"480":
slidesPerView: 5
"640":
slidesPerView: 5
grabCursor: true
initalSlide: 0
keyboard: true
mousewheel: true
observeSlideChildren: true
observer: true
runCallbacksOnInit: true
spaceBetween: 0
updateOnWindowResize: true
watchOverflow: true
style:
--swiper-navigation-color: var(--weather-card-text-color)
--swiper-navigation-size: 30px
visible: =vars.tab === 'precip_forecast'
slots:
default:
- component: oh-repeater
config:
for: hour
fragment: true
rangeStart: 0
rangeStop: "=(props.forecastHours === undefined) ? 12 : Number(props.forecastHours)"
sourceType: range
slots:
default:
- component: f7-swiper-slide
config:
expandable: true
id: =loop.hour_idx
style:
background: "=(props.sunIndicator) ? ((dayjs().add(loop.hour,'hour').format() >= items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunrise'].state && dayjs().add(loop.hour,'hour').format() <= items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunset'].state) ? (!props.sunIndicatorColorDay ? 'rgba(255,255,255,.2)' : props.sunIndicatorColorDay) : (!props.sunIndicatorColorNight ? 'rgba(41,109,152,.2)' : props.sunIndicatorColorNight)) : 'none'"
border-radius: 5px
slots:
default:
- component: f7-icon
config:
f7: sun_max_fill
size: 17px
style:
color: var(--weather-card-text-color)
cursor: pointer
position: absolute
right: 3px
top: 3px
z-index: 998
tooltip: "=((!props.wordingSunrise) ? 'Sunrise at ' : props.wordingSunrise + ' ') + ((!props.dateFormat) ? dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunrise'].state).format('h:mm A') : dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunrise'].state).format('H:mm') + (!props.timestampSuffix ? '' : ' ' + props.timestampSuffix) ) + '<br><b>' + dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunrise'].state).fromNow() + '</b>'"
visible: "=(dayjs().add(loop.hour,'hour').startOf('hour').format() === dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunrise'].state).startOf('hour').format() && props.sunIndicator === true)"
- component: f7-icon
config:
f7: moon_fill
size: 17px
style:
color: var(--weather-card-text-color)
cursor: pointer
position: absolute
right: 3px
top: 3px
z-index: 998
tooltip: "=((!props.wordingSunset) ? 'Sunset at ' : props.wordingSunset + ' ') + ((!props.dateFormat) ? dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunset'].state).format('h:mm A') : dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunset'].state).format('H:mm') + (!props.timestampSuffix ? '' : ' ' + props.timestampSuffix) ) + '<br><b>' + dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunset'].state).fromNow() + '</b>'"
visible: "=(dayjs().add(loop.hour,'hour').startOf('hour').format() === dayjs(items[((!props.itemPrefix) ? '' : props.itemPrefix) + 'Forecast' + (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').format() ? 'Today' : (dayjs().add(loop.hour,'hour').startOf('day').format() === dayjs().startOf('day').add(1,'day').format() ? 'Tomorrow' : 'Day2')) + '_Sunset'].state).startOf('hour').format() && props.sunIndicator === true)"
- component: f7-row
config:
class:
- justify-content-center
- align-items-center
slots:
default:
- component: Label
config:
style:
color: var(--weather-card-text-color)
font-size: var(--weather-font-size-slider-text)
font-weight: 700
text-transform: var(--weather-text-transform-time)
text: "=(loop.hour === 0) ? ((!props.wordingNow) ? 'Now' : props.wordingNow) : ((!props.dateFormat) ? dayjs().add(loop.hour,'hour').startOf('hour').format('h A') : dayjs().add(loop.hour,'hour').startOf('hour').format('H')) + (!props.timestampSuffix ? '' : ' ' + props.timestampSuffix)"
- component: f7-col
config:
class:
- justify-content-center
- align-items-center
- text-align-center
slots:
default:
- component: f7-icon
config:
f7: umbrella_fill
size: var(--weather-icon-size-slider)
style:
color: var(--weather-card-text-color)
padding-bottom: 5px
padding-top: 5px
- component: Label
config:
style:
color: var(--weather-card-text-color)
font-size: var(--weather-font-size-slider-text-temp-max-min-pr)
font-weight: 400
text: "=Math.round(items[((!props.itemPrefix) ? '' : props.itemPrefix) + ((loop.hour === 0) ? 'Current_Rain' : 'ForecastHours' + ((loop.hour_idx < 10 ? '0'+(loop.hour_idx) : loop.hour_idx))) + '_Precipprobability'].state.split(' ')*100) + ((loop.hour === 0) ? ' min' : '%')"
into f7-card I inserted aspect-ratio: 1.7
but if I will add also :
display: flex
align-items: center
justify-content: center
complete layout is lost
I think problem is s7-segmented and s7-swiper used ?
thanks
Alex
As the widgets become more complex, keeping track of all the parameters that can go into the flexbox calculations can be difficult.
In this case I believe the issue is entirely the swiper. The flex parameters that worked before don’t work here, because they impose no width constraint down the tree and so the swiper can grow to be as wide as it wants with no regard for the actual width of the containing elements.
The quickest fix here would be to use the following instead on the f7-card:
display: flex
flex-direction: column
align-items: stretch
justify-content: center
That would be the quickest and the easiest, but you may find that it’s not the best because it’s going to leave a bunch of space above and below the content.
If you want to also change the shape of the f7-blocks so that they fill the space better then you will get a better looking result but it will be a lot more work because you will have to change some of the styling for the internal elements as well.
f7-card modification
display: flex
flex-direction: column
align-items: stretch
justify-content: center
works quite good. White space above and below is quite ok, but I’m also interested about more difficult way, because maybe it will help me learn more…
Can you please explain this more difficukt way ?
Thank you
There’s no one more difficult way. There are dozens of options. My point was that this complex widget already has detailed styling for its basic layout. You are changing the fundamental style philosophy (forcing an aspect ratio rather than let the contents determine the shape of the container). There’s nothing wrong with that but, such a fundamental change to the base components is going to have consequences all the way down the tree, and if you want to make your new style comprehensive then you will likely also have to make changes to most of the components all the way down the tree.
Ok, I understand. I want do it step by step. But I’m not sure how to start with this change. Maybe first of all I need to understand how layout building is working and how aspect ration + display flex in the card style is working, because right now isn’t compatible with s7-swiper.
edit: What I have problem is understand layout philosophy. What is container (s7-card or s7-block or ??) and what is item in the container. Is it oh-label, oh-button or s7-row, s7-col etc… ?
There are lots of different ways to use css to arrange html elements so one of the hardest parts is often selecting the basic method that fits the job at hand the most closely. If you’re really interested in exploring more about the basics and building up your understanding, then I recommend taking a look at any one of the many CSS tutorials/introductions that can be found on the web. One example would be:
but there are hundreds of good free options to choose from.
The way swiper card is included in the weather widget, it is going to expand its width to fit as many slides as possibile until it reachers some maximum width defined by one of the elements above it. When you move the card over to a flexbox display it turns out that you are removing the that limit, so the swiper expands to its full width even though that is much larger than the width of the card. There’s no one way to fix this, there’s no best way to fix this. But learning how each element uses the sizes of its children and/or parents to determine its size is one parts of CSS that often takes people the longest to really get comfortable with.
One of the most general terms for each piece of an html page is element (you will also see node as an even more general term because that extends to many tag based markup languages). In a tree based structure such as html, each element is going to have one parent (unless it is the root node of the tree) and zero or more child nodes.
<parent>
<element>
<child1>
<child2>
Container is often synonymous with parent but doesn’t have to be. If you are talking about some element, say a text paragraph (a <p> element) then container would be a less precise term that just refers to any element above that <p> in the tree that is controlling some of the styling of the <p> element.
<div> <- this div is acting as a container for the importantText p and the uselessText p
<div> <- this div is a container only for the importantText p
<p id="importantText">...</p>
</div>
<div> <- this div is a container only for the uselessText p
<p id="uselessText">...</p>
</div>
</div>
