IpCamera: New IP Camera Binding

I agree it should be in the Readme, however we should also consider asking reolink if this is a bug on their end. Right now we have people asking that the binding can get the ability to turn the push notifications on and off with the binding, so that causes a conflict and addressing it at documentation is not as good as someone asking reolink about it. I don’t own one so it needs to be someone else.

Well, amazingly they released a new Client application yesterday that seems to clear up the answer a bit better! (This is only their client app and not new firmware for the doorbell).

I was wrong in my descriptions above about what Push notifications are, but only because of how the previous software was laid out (Im going to edit my posts above to make sure Im clear about this).

It looks like Push notifications are actual API level push notifications (the ones that the doorbell will send out as an alert) based on:

-The time schedule you set (this applies as a group to ALL 3 of the below options)

  • Visitor (Someone pressing the doorbell button)
  • Person (AI detection of a person)
  • Any Motion (AI detection of other large objects e.g. cars. a horse etc)

So these are the things (Visitor, Person, Any Motion) that people would probably want to be able to turn off and on.

If you disable Push on the camera, you will get no alerts on your phone app OR sent to Openhab. The push setting doesn’t disable the API, only the alert types and schedule it works on.

Ive had a little glance at their current API API-April, 2023 – Google Drive

I think its pages 164 to 174 that relate to these features and getting/setting via API.

I did note here on their forums that some API options are either not yet documented in the doorbell OR not yet in the firmware of the doorbell Reolink Camera API User Guide_V8 (Updated in April 2023) | Reolink Community So maybe that means that current firmware may or may not support the API requests mentioned.

Im happy to try query it/get a response from any settings, if you can tell me what you want (and I can figure out how to do it).

Dear all, i am searching for a compatible outdoor camera for my house door. Mandatory feature would be a detection alarm in openhab because i dont have a smart door bell. I do have a wall tablet, there i want to show the video stream as soon as a motion is detected. Nice to have would be person detection.

Availability in Germany (Amazon?) And budget maybe 100€ would be great. Can someone give a recommendation?

I am using openhab 4.0.4 on a Raspberry pi 3b+. Is this hardware sufficient?

Thank you :blush:

The very first post of this thread has the brands that work and the different features that they all offer. Instar is a German company and works well and has good support, check if they are in your budget range.

Thank you for the quick answer :slight_smile:
Yes i read the first post, but i was not sure if it was update since 2018. If its up to date i can kf course just check availability and price of the recommended cameras.

The 2 recommended instar cameras are above my price expectations, and one of them seems to be only indoor.

Found this one INSTAR IN-8403
It reasonable priced and availableon amazon (130€). Do you know if its compatible?
Edit: IN-8403 seems to LAN cable connection only, i would need wifi connection.

Thought there is maybe a price / performance champion known in the openhab community :smiley:

It should be compatible as it is the newer Sony Starvis 1/2.8" sensor range so it will have the Instar API in it. The list of models in the first post are ones that people have reported back that work, many many more will work just fine it is just no one has bothered to reply back and most people that have working gear do not post.

If you want to buy purely on price alone and do not value support and firmware updates, then you can look at Ankke which can have Hikvision firmware loaded onto them, and Amcrest which are Dahua hardware and have their API in them with stock firmware. Dahua and Hikvision are both Chinese and you will not get firmware released as often if you buy one of the OEM re-branded units, but they will be the cheapest prices along with Reolink.

You need to weigh up the advantage of a camera with good after sales support, regular firmware and security updates and the quality of the picture quality when you account for day and night vision.

If you like the idea of full colour at night time, then you may be willing to pay extra for a starlight / starvis / Ultra Low Light or whatever the brand likes to call the Sony Starvis sensors.

If you want to learn about cameras above just the price, then head to a forum with people that know more than I do here and they post footage to compare:

hello people, I asked this in Sep but the problem is still here despite updates and testing

when i did the transition from 3.X to 4.0 i had some issues on logging etc which i corrected - but what seems to be consistently problematic is that my 20 cameras (RSTP) which are also displayed on habpanel/with the clickable widget (but this doesnt seem to be the issue) are causing memory issues / resources usage issues.

Basically, when i install the binding (having added ffmpeg) over time the memory as observed via system info binding decreases slowly. It eventaully reaches a point where the system hangs and i get alerts on resource errors/availability. Rules fail.

I tried uninstalling the binding and reinstalling
Removing the things and recreating them.

My current test incase it is a upgrade issue is that I just setup a clean install only with IPcamera to see if it is something else on the system and am waiting a few days. but first signs is that the memory is dropping by .1% every 1hour or so. I will leave it to see if it hangs

Has anyone had a similar experience?

thanks for your time!

Dear all, i bought myself a Instar IN9008 FullHD camera and integrated it to Openhab today.
I installed ffmpeg on my RPI with Openhabian by sudo apt install ffmpeg showing now:

openhabian@openhabian:~ $ ffmpeg -version
ffmpeg version 4.3.6-0+deb11u1+rpt5 Copyright (c) 2000-2023 the FFmpeg developers
built with gcc 10 (Raspbian 10.2.1-6+rpi1)
configuration: --prefix=/usr --extra-version=0+deb11u1+rpt5 --toolchain=hardened --incdir=/usr/include/arm-linux-gnueabihf --enable-gpl --disable-stripping --enable-avresample --disable-filter=resample --enable-gnutls --enable-ladspa --enable-libaom --enable-libass --enable-libbluray --enable-libbs2b --enable-libcaca --enable-libcdio --enable-libcodec2 --enable-libdav1d --enable-libflite --enable-libfontconfig --enable-libfreetype --enable-libfribidi --enable-libgme --enable-libgsm --enable-libjack --enable-libmp3lame --enable-libmysofa --enable-libopenjpeg --enable-libopenmpt --enable-libopus --enable-libpulse --enable-librabbitmq --enable-librsvg --enable-librubberband --enable-libshine --enable-libsnappy --enable-libsoxr --enable-libspeex --enable-libsrt --enable-libssh --enable-libtheora --enable-libtwolame --enable-libvidstab --enable-libvorbis --enable-libvpx --enable-libwavpack --enable-libwebp --enable-libx265 --enable-libxml2 --enable-libxvid --enable-libzmq --enable-libzvbi --enable-lv2 --enable-omx --enable-openal --enable-opencl --enable-opengl --enable-sdl2 --enable-mmal --enable-neon --enable-rpi --enable-v4l2-request --enable-libudev --enable-epoxy --enable-pocketsphinx --enable-libdc1394 --enable-libdrm --enable-vout-drm --enable-libiec61883 --enable-chromaprint --enable-frei0r --enable-libx264 --enable-shared --libdir=/usr/lib/arm-linux-gnueabihf --cpu=arm1176jzf-s --arch=arm
libavutil      56. 51.100 / 56. 51.100
libavcodec     58. 91.100 / 58. 91.100
libavformat    58. 45.100 / 58. 45.100
libavdevice    58. 10.100 / 58. 10.100
libavfilter     7. 85.100 /  7. 85.100
libavresample   4.  0.  0 /  4.  0.  0
libswscale      5.  7.100 /  5.  7.100
libswresample   3.  7.100 /  3.  7.100
libpostproc    55.  7.100 / 55.  7.100

Under /usr/bin there is now a file called ffmpeg. I hope this is okay …

Then i configured the ip camera thing:

UID: ipcamera:instar:980dac2114
label: Instar Camera with API
thingTypeUID: ipcamera:instar
  mjpegOptions: -q:v 5 -r 2 -vf scale=640:-2 -update 1
  updateImageWhen: "0"
  gifPreroll: 0
  onvifPort: 8080
  ffmpegLocation: /usr/bin/ffmpeg
  ipWhitelist: DISABLE
  mp4OutOptions: -c:v copy -c:a copy
  pollTime: 1000
  password: PASSWORD
  port: 80
  snapshotOptions: -an -vsync vfr -q:v 2 -update 1
  ptzContinuous: true
  onvifMediaProfile: 0
  username: USERNAME
  hlsOutOptions: -strict -2 -f lavfi -i aevalsrc=0 -acodec aac -vcodec copy
    -hls_flags delete_segments -hls_time 2 -hls_list_size 4
  gifOutOptions: -r 2 -filter_complex

Now i am a little bit lost.
What i want to do is to have a PIR trigger and a video stream on a openhab page.
But channel Motion alarm stays OFF all the time. I have to PIR enabled in the web UI and its also triggering in mqtt. As a backup i can use the mqtt channel …
Then i put a item to MJPEG URL Image URL and HLS URL. They all have a URL now. MJPEG URL is showing a good stream in the browser, Image URL and image only. HSL URL wants to download something. Now i put the MJPEG item into a video card in a openhab page but the card shows No compatible source was found for this media. The Image Card Image URL is showing the camera image, i can set the refresh rate to 500 ms but below this the image does not refresh. Using the HLS URL in the video card is resulting in a very delayed video (~30sec). What is the best way to do this? Can someone give me a hint? (Sorry for the long text)

edit: Ok managed to fix it. There is another PIR channel which is working. And for the MJPEG i also have to use the image card :smiley:

I want to setup something like a event historie to show the last 3 motion triggered pictures / short videos in the UI. I managed to save the gif files on my raspberry pi with the date ans time as file name. Does someone know how to show them on a openhab page? I only do have the path and file name.

There is a widget in the marketplace for doing exactly that.

Hi, thank you for your answer. This sounds good. I checked all the widgets in the marketplace but didnt find something which may help for this. Which exactly do you mean?

I think me means this one…

FFmpeg stopped to give snapshot for generica RTSP camera.
I have such an EZVIZ C6N that worked for months:

Thing ipcamera:generic:sala “Webcam Sala” @ “Webcams”
[ ipAddress=“”,
snapshotOptions=“-an -vsync vfr -q:v 2 -update 1”,
polltime = 2000,
Now it stopped to display the snapshot in my sitemap
Image url=“http://mhw.int.fmal.com:8080/ipcamera/sala/ipcamera.jpg” refresh=2000

I traced the log

2023-11-30 21:19:36.282 [INFO ] [el.core.internal.ModelRepositoryImpl] - Loading model 'Webcam.things'
2023-11-30 21:19:36.339 [DEBUG] [hab.binding.ipcamera.internal.Ffmpeg] - Stopping ffmpeg SNAPSHOT now when keepalive is:8
2023-11-30 21:19:40.361 [DEBUG] [era.internal.handler.IpCameraHandler] - Binding has no snapshot url. Will use your CPU and FFmpeg to create snapshots from the cameras RTSP.
2023-11-30 21:19:40.363 [DEBUG] [hab.binding.ipcamera.internal.Ffmpeg] - Starting ffmpeg with this command now:-rtsp_transport tcp -threads 1 -skip_frame nokey -hide_banner -i rtsp://admin:********@ -an -vsync vfr -q:v 2 -update 1
2023-11-30 21:19:45.972 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - [rtsp @ 0x12369c0] decoding for stream 0 failed
2023-11-30 21:19:45.974 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - Input #0, rtsp, from 'rtsp://admin:WOAKEU@':
2023-11-30 21:19:45.975 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -   Metadata:
2023-11-30 21:19:45.976 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -     title           : Media Presentation
2023-11-30 21:19:45.977 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -   Duration: N/A, start: 144899.397000, bitrate: N/A
2023-11-30 21:19:45.977 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -     Stream #0:0: Video: h264 (Main), yuvj420p(pc, bt709, progressive), 1920x1080, 12 fps, 12 tbr, 90k tbn, 24 tbc
2023-11-30 21:19:45.978 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -     Stream #0:1: Audio: aac (LC), 16000 Hz, mono, fltp
2023-11-30 21:19:45.979 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - Stream mapping:
2023-11-30 21:19:45.979 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -   Stream #0:0 -> #0:0 (h264 (native) -> mjpeg (native))
2023-11-30 21:19:45.980 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - Press [q] to stop, [?] for help
2023-11-30 21:19:46.067 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - Output #0, image2, to '':
2023-11-30 21:19:46.067 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -   Metadata:
2023-11-30 21:19:46.068 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -     title           : Media Presentation
2023-11-30 21:19:46.069 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -     encoder         : Lavf58.45.100
2023-11-30 21:19:46.069 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -     Stream #0:0: Video: mjpeg, yuvj420p(pc), 1920x1080, q=2-31, 200 kb/s, 12 fps, 12 tbn, 12 tbc
2023-11-30 21:19:46.070 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -     Metadata:
2023-11-30 21:19:46.070 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -       encoder         : Lavc58.91.100 mjpeg
2023-11-30 21:19:46.071 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -     Side data:
2023-11-30 21:19:46.072 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] -       cpb: bitrate max/min/avg: 0/0/200000 buffer size: 0 vbv_delay: N/A
2023-11-30 21:19:46.552 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - frame=    0 fps=0.0 q=0.0 size=N/A time=00:00:00.00 bitrate=N/A dup=0 drop=1 speed=   0x
2023-11-30 21:19:47.094 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - frame=    0 fps=0.0 q=0.0 size=N/A time=00:00:00.00 bitrate=N/A dup=0 drop=1 speed=   0x
2023-11-30 21:19:47.631 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - frame=    0 fps=0.0 q=0.0 size=N/A time=00:00:00.00 bitrate=N/A dup=0 drop=1 speed=   0x
2023-11-30 21:19:48.175 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - frame=    0 fps=0.0 q=0.0 size=N/A time=00:00:00.00 bitrate=N/A dup=0 drop=1 speed=   0x
2023-11-30 21:19:48.676 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - frame=    0 fps=0.0 q=0.0 size=N/A time=00:00:00.00 bitrate=N/A dup=0 drop=1 speed=   0x
2023-11-30 21:19:49.158 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - frame=    0 fps=0.0 q=0.0 size=N/A time=00:00:00.00 bitrate=N/A dup=0 drop=1 speed=   0x
2023-11-30 21:19:49.673 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - frame=    0 fps=0.0 q=0.0 size=N/A time=00:00:00.00 bitrate=N/A dup=0 drop=1 speed=   0x
2023-11-30 21:19:50.226 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - frame=    0 fps=0.0 q=0.0 size=N/A time=00:00:00.00 bitrate=N/A dup=0 drop=1 speed=   0x
2023-11-30 21:19:50.768 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - frame=    0 fps=0.0 q=0.0 size=N/A time=00:00:00.00 bitrate=N/A dup=0 drop=2 speed=   0x
2023-11-30 21:19:51.263 [TRACE] [hab.binding.ipcamera.internal.Ffmpeg] - frame=    0 fps=0.0 q=0.0

It looks as noting is captured from ffmpeg…
TY for advices
