uid: Licht-Widget
component: oh-list-card
config:
title: Licht Steuerung
accordionList: true
slots:
default:
- component: oh-list-item
config:
title: Flur
icon: oh:corridor
badge: =items.Licht_Flur_Power.state
badgeColor: '=items.Licht_Flur_Power.state === "ON" ? "green" : "red"'
slots:
accordion:
- component: oh-list
config:
accordionList: true
class:
- margin-left
slots:
default:
- component: oh-list-item
config:
title: Steuerung allgemein
footer: '=items.Licht_Flur_Power.state === "ON" ? items.Licht_Flur_Watt.state : ""'
badge: =items.Licht_Flur_Power.state
badgeColor: '=items.Licht_Flur_Power.state === "ON" ? "green" : "red"'
slots:
accordion:
- component: oh-list
config:
accordionList: true
class:
- margin-left
slots:
default:
- component: oh-toggle-item
config:
title: Power
item: Licht_Flur
icon: oh:switch
- component: oh-slider-item
config:
item: Licht_Flur_R
title: Rot
- component: oh-slider-item
config:
item: Licht_Flur_G
title: Grün
- component: oh-slider-item
config:
item: Licht_Flur_B
title: Blau
- component: oh-slider-item
config:
item: Licht_Flur_Gain
title: Helligkeit
- component: oh-slider-item
config:
item: Licht_Flur_W
title: Weiß
- component: oh-list-item
config:
title: Steuerung vorne
footer: '=items.Licht_Flur_vorne_Power.state === "ON" ? items.Licht_Flur_vorne_Watt.state : ""'
badge: =items.Licht_Flur_vorne_Power.state
badgeColor: '=items.Licht_Flur_vorne_Power.state === "ON" ? "green" : "red"'
slots:
accordion:
- component: oh-list
config:
accordionList: true
class:
- margin-left
slots:
default:
- component: oh-toggle-item
config:
title: Power
item: Licht_Flur_vorne_Power
icon: oh:switch
- component: oh-slider-item
config:
item: Licht_Flur_vorne_R
title: Rot
- component: oh-slider-item
config:
item: Licht_Flur_G
title: Grün
- component: oh-slider-item
config:
item: Licht_Flur_vorne_B
title: Blau
- component: oh-slider-item
config:
item: Licht_Flur_vorne_Gain
title: Helligkeit
- component: oh-slider-item
config:
item: Licht_Flur_vorne_W
title: Weiß
- component: oh-list-item
config:
title: Steuerung hinten
footer: '=items.Licht_Flur_hinten_Power.state === "ON" ? items.Licht_Flur_hinten_Watt.state : ""'
badge: =items.Licht_Flur_vorne_Power.state
badgeColor: '=items.Licht_Flur_vorne_Power.state === "ON" ? "green" : "red"'
slots:
accordion:
- component: oh-list
config:
accordionList: true
class:
- margin-left
slots:
default:
- component: oh-toggle-item
config:
title: Power
item: Licht_Flur_hinten_Power
icon: oh:switch
- component: oh-slider-item
config:
item: Licht_Flur_R
title: Rot
- component: oh-slider-item
config:
item: Licht_Flur_hinten_G
title: Grün
- component: oh-slider-item
config:
item: Licht_Flur_hinten_B
title: Blau
- component: oh-slider-item
config:
item: Licht_Flur_hinten_Gain
title: Helligkeit
- component: oh-slider-item
config:
item: Licht_Flur_hinten_W
title: Weiß
- component: oh-list-item
config:
title: Wohnzimmer
icon: oh:sofa
badge: =items.Licht_Wohnzimmer_Power.state
badgeColor: '=items.Licht_Wohnzimmer_Power.state === "ON" ? "green" : "red"'
background-color: red
slots:
accordion:
- component: oh-list
config:
accordionList: true
class:
- margin-left
slots:
default:
- component: oh-list-item
config:
title: Steuerung allgemein
footer: '=items.Licht_Wohnzimmer_Power.state === "ON" ? items.Licht_Wohnzimmer_Watt.state : ""'
badge: =items.Licht_Wohnzimmer_Power.state
badgeColor: '=items.Licht_Wohnzimmer_Power.state === "ON" ? "green" : "red"'
slots:
accordion:
- component: oh-list
config:
accordionList: true
class:
- margin-left
slots:
default:
- component: oh-toggle-item
config:
title: Power
item: Licht_Wohnzimmer_Power
icon: oh:switch
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_R
title: Rot
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_G
title: Grün
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_B
title: Blau
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_Gain
title: Helligkeit
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_W
title: Weiß
- component: oh-list-item
config:
title: Steuerung TV
footer: '=items.Licht_Wohnzimmer_TV_Dimmer.state === "ON" ? items.MeterWatts.state : ""'
badge: =items.Licht_Wohnzimmer_TV_Dimmer.state
badgeColor: '=items.Licht_Wohnzimmer_TV_Dimmer.state === "ON" ? "green" : "red"'
slots:
accordion:
- component: oh-list
config:
accordionList: true
class:
- margin-left
slots:
default:
- component: oh-toggle-item
config:
title: Power
item: Licht_Wohnzimmer_TV_Dimmer
icon: oh:switch
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_TV_R
title: Rot
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_TV_G
title: Grün
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_TV_B
title: Blau
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_TV_H
title: Helligkeit
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_TV_W
title: Weiß
- component: oh-list-item
config:
title: Steuerung Kamin
footer: '=items.Licht_Wohnzimmer_Kamin_Dimmer.state === "ON" ? items.MeterWatts_K.state : ""'
badge: =items.Licht_Wohnzimmer_Kamin_Dimmer.state
badgeColor: '=items.Licht_Wohnzimmer_Kamin_Dimmer.state === "ON" ? "green" : "red"'
slots:
accordion:
- component: oh-list
config:
accordionList: true
class:
- margin-left
slots:
default:
- component: oh-toggle-item
config:
title: Power
item: Licht_Wohnzimmer_Kamin_Dimmer
icon: oh:switch
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_Kamin_R
title: Rot
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_Kamin_G
title: Grün
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_Kamin_B
title: Blau
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_Kamin_H
title: Helligkeit
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_Kamin_W
title: Weiß
- component: oh-list-item
config:
title: Steuerung Fenster
footer: '=items.Licht_Wohnzimmer_Fenster_Dimmer.state === "ON" ? items.MeterWatts_F.state : ""'
badge: =items.Licht_Wohnzimmer_Fenster_Dimmer.state
badgeColor: '=items.Licht_Wohnzimmer_Fenster_Dimmer.state === "ON" ? "green" : "red"'
slots:
accordion:
- component: oh-list
config:
accordionList: true
class:
- margin-left
slots:
default:
- component: oh-toggle-item
config:
title: Power
item: Licht_Wohnzimmer_Fenster_Dimmer
icon: oh:switch
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_Fenster_R
title: Rot
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_Fenster_G
title: Grün
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_Fenster_B
title: Blau
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_Fenster_H
title: Helligkeit
- component: oh-slider-item
config:
item: Licht_Wohnzimmer_Fenster_W
title: Weiß
Is it possible to format a number value in a badge.
If i do this
badge: =items.Power_Office.state
all decimal values are shown as well. i just want e. g. 2 decimal numbers
Also tried it with the following - without success:
color: ='(items.HM_WZ_Heizung_Humidity.state) > '50' ? "green"'
color: ='(items.HM_WZ_Heizung_Humidity.state) > 50 ? "green"'
color: ='(items.HM_WZ_Heizung_Humidity.state as Number) > '50' ? "green"'
color: ='(items.HM_WZ_Heizung_Humidity.state as Number) > 50 ? "green"'
Could someone help me and tell me what the correct term should be?
You’re missing the ‘else’ statement in your expression and have to enclose the whole expression with the quotes (including the =) - like this:
color: '=(items.HM_WZ_Heizung_Humidity.state > 50 ) ? "green" : ""'
That doesnt work, too - the colors dont change:
color: '=(items.HM_WZ_Heizung_Humidity.state) > 50 ? "green" : "red"'
I was wondering if someone could help me too.
I’ve got a virtual switch ‘Presence’, this has been placed on a label card on the Overview page.
I wanted some conditional formatting to change the background color based on its state.
I’ve got the following:
background: "=(items.Presence.state == ON) ? '#77dd77' : '#ff6961'"
Now, the issue is that the background color always defaults to the false color…any ideas why? I’m certain that the switch is ‘ON’.
Any help would be greatly appreciated
I’d guess that your item is not number then, isn’t it? Or at least it is formated as a ‘Number:Dimensionless’ - in that case you have to do:
'=(items.HM_WZ_Heizung_Humidity.state > "50 %") ? "green" : "red"'
Hi @Jeevs
In case of the ‘oh-label-card’ the background is a config parameter, which only applies to the content part - if this is enough for your scenario, just put your background expression in the config-part.
Any other background styles get overwritten by the standard widget itself.
That doesnt work, too. The item is formated just as number, but has a pattern at meta description (i think this doesnt matter?).
It shouldn’t as the .state just takes the raw item state. Could you try to create this custom widget please and tell me what’s happening with the background and whats the title label:
uid: test
component: f7-card
config:
title: =items.HM_WZ_Heizung_Humidity.state
style:
background: '=(items.HM_WZ_Heizung_Humidity.state > 50) ? "green" : "red"'
Oh, and maybe it would be better to create a new topic for your problem as we spam this thread a bit too much with specific problems that doesn’t belong here…
At the seperate widget it works fine. After i added “style:” to the card-yaml it works fine, too.
Many thanks for your help!
Hi @RGroll
Yes, I’m using the ‘oh-label-card’. Not sure I quite understand that content part? Do you mean with the standard widget I can only change the background color of the text itself? Rather than the whole box?
This is my YAML for the widget:
component: oh-label-card
config:
title: Presence
item: Presence
background: "=(items.Presence.state == ON) ? '#4cd964' : '#ff3b30'"
icon: oh:presence
Thank you!
Can’t find a way to access the label of an item in custom widget.
Sorry if this have been answered already somewhere …
In the props section, I’m going to ask for some items, e.g.:
props:
parameters:
- context: item
label: PowerState Item
name: powerstateItem
required: true
type: TEXT
...
Later in the widget’s components, I’d like to access the items states but also sometimes the label of the item what I trying to interact with, e.g.:
slots:
default:
- component: Label
config:
text: = items[props.powerstateItem].label
… which is not working that way
What’s the intended way to access the label of an item for use in a widget?
Fiddling around with the new possibilities like others here, I’m searching for a way to specify the column width of f7-col item.
The code for this is:
config:
style:
border-radius: 20px
background-color: rgba(6,25,36)
--text-color: rgba(255,255,255,1)
slots:
default:
- component: f7-block
config:
class:
- padding
slots:
default:
- component: f7-row
config:
class:
- padding-top
slots:
default:
- component: f7-block
slots:
default:
- component: f7-row
slots:
default:
- component: f7-col
slots:
default:
- component: oh-image
config:
url: /static/icons/tv.svg
style:
width: 25px
- component: f7-col
slots:
default:
- component: Label
config:
text: ="TVAV Zimmer"
style:
color: var(--text-color)
font-size: 18px
line-height: 30px
text-align: right
white-space: nowrap
overflow: hidden
text-overflow: ellipsis
The column containing the tv.svg image I like to justify in width
component: f7-col
slots:
default:
- component: oh-image
config:
url: /static/icons/tv.svg
style:
width: 25px
Any suggestion is welcome.
Generally you could set the width of each column with the config parameter width:
as described here
But I think in your case it would be more usefull to get rid of the columns at all and just use the row where you align your contents in - something like:
component: f7-card
config:
style:
border-radius: 20px
background-color: rgba(6,25,36)
--text-color: rgba(255,255,255,1)
slots:
default:
- component: f7-block
config:
class:
- padding
slots:
default:
- component: f7-row
config:
style:
flex-wrap: nowrap
slots:
default:
- component: f7-icon
config:
f7: tv
size: 30
color: white
class:
- padding-right
- component: Label
config:
text: ="TVAV Zimmer"
style:
color: var(--text-color)
font-size: 18px
line-height: 30px
text-align: left
white-space: nowrap
overflow: hidden
text-overflow: ellipsis
Thank you!
These widgets look great. But how do I have to use the source code provided at GitHub - rgrollfitz/oh3-widgets ? I added them on the developer page and now I have them under “Personal Widgets”.
But I only have sliders and switches on the widget. Now I want to use them for thermostats, displaying actual temperature history as a graph in the background and setting the desired temperature. Plus, I would like to show the humidity. This is shown in the images above for the dimmer control, but what are the required settings?
- How to include the nice graph in the widget background?
- Where should I put the images provided in the github archive?
- How can I include those images?
- How can I add the humidity information?
Sorry for posting so many questions, but for me, this widget topic is quite confusing and beyond any experience… Thanks!
Hey @Tobi77
this was one of my first experiments with the YAML structure and wasn’t updated since - so there might be some missing parts in documentation as well as in function.
It was more a first proof-of-concept how standard components of the MainUI would fit into a custom widget. So please be indulgent
You can enable/disable every control-element using the widget-configuration.
There’s no support for graphs in this widget. It could be added but wouldn’t fit the look & feel very well - The used oh-trend
component isn’t very flexible regarding styling atm.
Setting the desired temperature is possible with one of the control-elements (like slider, stepper buttons and so on) after you’ve defined the item you want to control (also in the widget-configuration setting)
If I got you right you want to show 2 values in the widget at the same time - like for example current temperature
and humidity
- this also isn’t supported as it was planned as a very simplistic approch to control & show a single item (yet?!).
Added an example with the integration of the oh-trend
component below
I updated the widget, that you don’t have to define the liquid-background anymore (as it’s implemented as an encoded inline-svg now)
You can set the path to the ‘hero-image’ (the one in the top-right corner) also inside the widget-configuration. The standard path would be /static/brightness_icon.svg
which corresponds to the path /etc/openhab/html/
in your OH-setup. But as said, you can set any url here.
What exactly you mean with ‘include’? Putting it inside the widget so you don’t need to load any images from another server? If you want to, you can customize the code so it loads the encoded svg as css-attirbute (this converter might help you with that)
But it remains - this widget still serves more a proof-of-concept approach (and maybe some small real-life usecases) as it’s not finished. Maybe I’ll find time to make it more configurable (and usable) in the future - but this isn’t my first priority right now tbh.
Nevertheless I updated the widget a bit to make it at least a bit more accessible and cleaned up the configuration section…
Widget YAML
uid: darkLiquid_card
tags:
- small
- dark
- custom
- liquid
props:
parameters:
- context: item
description: Set an item which you want to control
label: Item
name: item
required: false
type: TEXT
groupName: general
- label: Value symbol
description: The value symbol shown after the item-value
name: valueSymbol
required: false
type: TEXT
groupName: general
- description: valueSymbol high or low
label: Value symbol position
name: valueSymbolPos
required: false
type: BOOLEAN
groupName: general
advanced: true
- description: Set the lowest value, that your item can have. (<b>default:</b> 0)
label: Items MIN value
name: minValue
required: false
type: TEXT
groupName: general
- description: Set the highest value, that your item can have. (<b>default:</b> 100)
label: Items MAX value
name: maxValue
required: false
type: TEXT
groupName: general
- description: Show trend graph instead of liquid background
label: Trend graph
name: showTrend
required: false
type: BOOLEAN
groupName: general
- label: Headline text
name: headline
required: false
type: TEXT
groupName: header
- label: Subheadline text
name: subheadline
required: false
type: TEXT
groupName: header
- label: Hero icon image url
name: heroIcon
required: false
type: TEXT
groupName: images
- description: Activating Stepper element to control item which you selected above
label: Show stepper buttons
name: showStepper
required: false
type: BOOLEAN
groupName: controls
- description: Activating Toggle element to control item which you selected above
label: Show toggle
name: showToggle
required: false
type: BOOLEAN
groupName: controls
- description: Activating Slider element to control item which you selected above
label: Show slider
name: showSlider
required: false
type: BOOLEAN
groupName: controls
parameterGroups:
- name: general
label: General settings
description: Most important widget settings
- name: header
label: Header area
- name: controls
label: Control settings
description: Controls to manipulate your item-state (only use one of them)
- name: images
label: Images
timestamp: Jan 9, 2021, 11:43:36 AM
component: f7-block
config:
style:
position: relative
-ms-user-select: None
-moz-user-select: None
-webkit-user-select: None
user-select: None
class:
- no-padding
- no-margin
slots:
default:
- component: oh-image
config:
url: "=props.heroIcon ? props.heroIcon : ''"
style:
position: absolute
top: -15px
right: -10px
width: 100%
max-width: min(max(50px, 15vw), 80px)
z-index: 99
- component: f7-card
config:
style:
max-height: 200px
background-color: rgb(57,60,76)
border-radius: 20px
overflow: hidden
position: relative
slots:
default:
- component: oh-repeater
config:
visible: "=props.showTrend ? false : true"
sourceType: range
for: liquid
rangeStart: "=!props.minValue ? 0 : Number(props.minValue)"
rangeStop: "=!props.maxValue ? 100 : Number(props.maxValue)"
slots:
default:
- component: f7-block
config:
visible: =items[props.item].state == loop.liquid_idx
style:
position: absolute
height: 100%
width: 100%
left: 0
bottom: "=Math.fround((Number(loop.liquid) - (!props.maxValue ? 100 : Number(props.maxValue))) * (100 / (!props.maxValue ? 100 : Number(props.maxValue) - (!props.minValue ? 0 : Number(props.minValue))))) + '%'"
z-index: 1
- component: f7-card-content
config:
style:
height: 100%
display: flex
flex-direction: column
position: relative
z-index: 999
slots:
default:
- component: f7-row
config:
style:
z-index: 999
slots:
default:
- component: f7-col
slots:
default:
- component: Label
config:
propsParameterGroup: header
text: '=(props.headline) ? props.headline : "Headline"'
style:
white-space: nowrap
text-overflow: ellipsis
overflow: hidden
display: block
width: 100%
color: rgba(255,255,255,1)
letter-spacing: .75px
font-size: min(max(14px, 4vw), 21px)
font-weight: 600
- component: Label
config:
actionPropsParameterGroup: header
text: '=(props.subheadline) ? props.subheadline : "Subheadline"'
style:
white-space: nowrap
text-overflow: ellipsis
overflow: hidden
color: rgba(255,255,255,.7)
letter-spacing: .75px
font-size: min(max(9px, 2.5vw), 12px)
- component: f7-row
config:
style:
z-index: 999
slots:
default:
- component: f7-col
config:
class: '=props.valueSymbolPos ? props.valueSymbolPos : "align-items-flex-end"'
style:
display: flex
justify-content: flex-start
position: relative
slots:
default:
- component: Label
config:
text: =items[props.item].state
style:
color: rgba(255,255,255,1)
text-shadow: 2px 2px rgba(0,0,0,.25)
font-size: min(max(32px, 9vw), 51px)
font-weight: 600
- component: Label
config:
text: =props.valueSymbol
style:
color: rgba(255,255,255,1)
text-shadow: 2px 2px rgba(0,0,0,.25)
font-size: min(max(21px, 5.75vw), 32px)
font-weight: 600
- component: f7-col
config:
style:
display: flex
align-self: center
justify-content: flex-end
align-items: flex-end
flex-direction: column
slots:
default:
- component: oh-icon
config:
icon: power
visible: =items[props.item].state === "0"
action: command
actionOptions: COMMAND
actionItem: =props.item
actionPropsParameterGroup: action
actionCommand: ON
width: 20
height: 20
style:
cursor: pointer
filter: invert()
- component: oh-icon
config:
icon: power
visible: =items[props.item].state > "0"
action: command
actionOptions: COMMAND
actionItem: =props.item
actionCommand: OFF
width: 20
height: 20
style:
cursor: pointer
filter: invert(14%) sepia(99%) saturate(7416%) hue-rotate(0deg) brightness(94%) contrast(114%)
- component: f7-row
slots:
default:
- component: f7-col
config:
class: '=props.alignActionLeft ? props.alignActionLeft : "justify-content-flex-end"'
style:
height: 28px
max-height: 28px
display: flex
slots:
default:
- component: oh-stepper
config:
class: '=props.showStepper ? props.showStepper : "display-none"'
raised: true
buttonsOnly: true
small: true
autorepeat: true
min: =props.minValue
max: =props.maxValue
step: 1
color: white
style:
list-style-type: none
item: =props.item
- component: oh-toggle
config:
class: '=props.showToggle ? props.showToggle : "display-none"'
color: yellow
item: =props.item
style:
align-self: flex-end
- component: oh-slider
config:
class: '=props.showSlider ? props.showSlider : "display-none"'
step: "1"
min: =props.minValue
max: =props.maxValue
item: =props.item
style:
align-self: flex-end
font-color: yellow
- component: oh-trend
config:
visible: "=props.showTrend ? true : false"
trendItem: =props.item
trendGradient:
- "#FFE7DD"
- "#FFD1BD"
style:
position: absolute
bottom: 0
left: 0
width: 100%
height: 100%
